Curtainside Trailer External Curtain Strap Over Center Buckle Strap with Combi Hook


Name:Curtainside Trailer External Curtain Strap Over Center Buckle Strap with Combi Hook
Model Number:JLOBS009
Width:2inch(50MM)
Length:0.7-1M
Load Capacity:325daN
Breaking Strength:750daN
Color:Black
Hook type:Combi hook
Inquiry

  • Curtainside Trailer External Curtain Strap Over Center Buckle Strap with Combi Hook

Product Description


This section contains our internal and external curtainside straps.

Overcenter straps are constructed using an overcenter buckle rather than a ratchet or cam buckle. Overcenter tie downs are a great solution for quick cinch applications. Overcenter buckles don’t ratchet tight, so they won’t create the same tension as a ratchet. However, they are frequently used to hold down tarping on the sides of trailers.

Curtain strap help to keep the side curtain on trailers securely in place. It is essential that your curtain side straps and buckles are of the highest quality to ensure safe and secure transportation of heavy goods our hard wearing curtain straps and buckles are made from 304 stainless steel or alloy steel with galvanized, resulting in a long lasting, durable securing system for your trailer side curtains. Providing the strength needed to keep a steady and secure hold on the curtain. Once the curtain has been closed and tensioned, simply tighten each Strap providing a snug fit.

Advantage: Sample available(To check quality), Customized design(logo printing, special fittings), Different packaging(Shrink, Blister, Polybag, Carton), Short lead time, Multiple payment method(T/T, LC, Paypal, Alipay).




Specification:

Model Number: JLOBS006

New or replacement, side curtain buckle strap only. Also known as a bottom or tail strap.

Curtainside bottom strap

  • Breaking Force Minimum (BFmin) 750daN (kg)- Lashing Capacity (LC) 325daN (kg)

  • 1400daN (kg) black polyester(or polypropylene) webbing < 7% elongation @ LC

  • Fitted with a combi hook to allow attachment to the chassis / side rave

  • Manufactured labelled in accordance with EN 12195-2:2001

Fits all common overcentre buckles that accept 45mm or 50MM wide webbing. Foldover end allows the strap to be retro fitted while preventing accidental release from the buckle.
Other lengths, widths and colours available bespoke manufactured to order.




Cautions:


Never use lashing strap for lifting.

Never use overload.

Do not twist webbing.

Protect the webbing from sharp or abrasive edges.

Periodic inspect the ratchet strap to ensure the tie down or webbing in good condition, or replace it at once.



Applications:





Process & Packing:
